Circular Disc Industrial magnet pure permanent magnet

Pure permanent magnet

Circular Disc Industrial Magnet, as a pure permanent magnet, has strong magnetic force and long-term stable magnetism. This magnet adopts a round disc design and is compact in structure, making it easy to install and use. It is made of high-quality magnetic materials, has excellent magnetic and physical properties, and can withstand harsh environments such as high temperature and high pressure. Circular Disc Industrial Magnet is widely used in industrial automation, machinery manufacturing, electronic equipment and other fields, such as the manufacturing and maintenance of key components such as motors, sensors, and instruments. Its powerful magnetic force can stably absorb and fix ferromagnetic substances, achieving precise positioning and operation.

Contact Us
  • Specifications
  • Do You Have Any Question?
  • Grade Remanence Induction Coercivity Intrinsic
    Coercivity     		 ๋Maximum Energy
    product    		 Working
    Temperature    		 Density
    Br HcB HcJ (BH)max Tw ρ
    T KGs KA/m KOe KA/m KOe KJ/m³ MGOe ℃ g/cm3
    General Process
    N38 1.23-1.30 12.3-13.0 ≥876 ≥11 ≥955 ≥12 287-318 36-40 ≤80 ≥7.5
    N40 1.26-1.32 12.6-13.2 ≥876 ≥11 ≥955 ≥12 302-334 38-42 ≤80 ≥7.5
    N42 1.29-1.35 12.9-13.5 ≥876 ≥11 ≥955 ≥12 318-350 40-44 ≤80 ≥7.5
    N45 1.32-1.38 13.2-13.8 ≥876 ≥11 ≥955 ≥12 334-366 42-46 ≤80 ≥7.5
    N48 1.37-1.43 13.7-14.3 ≥876 ≥11 ≥955 ≥12 358-390 45-49 ≤80 ≥7.5
    N50 1.40-1.45 14.0-14.5 ≥876 ≥11 ≥955 ≥12 374-406 47-51 ≤80 ≥7.5
    N52 1.42-1.48 14.2-14.8 ≥836 ≥10.5 ≥876 ≥11 390-422 49-53 ≤80 ≥7.5
    N55 1.46-1.51 14.6-15.1 ≥860 ≥10.8 ≥955 ≥12 406-438 51-55 ≤80 ≥7.5
    N38M 1.23-1.30 12.3-13.0 ≥915 ≥11.5 ≥1114 ≥14 287-318 36-40 ≤100 ≥7.5
    N40M 1.26-1.32 12.6-13.2 ≥939 ≥11.8 ≥1114 ≥14 302-334 38-42 ≤100 ≥7.5
    N42M 1.29-1.35 12.9-13.5 ≥963 ≥12.1 ≥1114 ≥14 318-350 40-44 ≤100 ≥7.5
    N45M 1.32-1.38 13.2-13.8 ≥987 ≥12.4 ≥1114 ≥14 334-366 42-46 ≤100 ≥7.5
    N48M 1.37-1.43 13.7-14.3 ≥1019 ≥12.8 ≥1114 ≥14 358-390 45-49 ≤100 ≥7.5
    N50M 1.40-1.45 14.0-14.5 ≥1043 ≥13.1 ≥1114 ≥14 374-406 47-51 ≤100 ≥7.5
    N52M 1.42-1.48 14.2-14.8 ≥1059 ≥13.3 ≥1114 ≥14 390-422 49-53 ≤100 ≥7.5
    N54M 1.46-1.51 14.6-15.1 ≥995 ≥12.5 ≥1035 ≥13 406-438 51-55 ≤100 ≥7.5
    N35H 1.17-1.24 11.7-12.4 ≥876 ≥11.0 ≥1353 ≥17 263-295 33-37 ≤120 ≥7.5
    N38H 1.23-1.30 12.3-13.0 ≥915 ≥11.5 ≥1353 ≥17 286-318 36-40 ≤120 ≥7.5
    N40H 1.26-1.32 12.6-13.2 ≥939 ≥11.8 ≥1353 ≥17 302-334 38-42 ≤120 ≥7.5
    N42H 1.29-1.35 12.9-13.5 ≥963 ≥12.1 ≥1353 ≥17 318-350 40-44 ≤120 ≥7.5
    N45H 1.32-1.38 13.2-13.8 ≥987 ≥12.4 ≥1353 ≥17 334-366 42-46 ≤120 ≥7.5
    N48H 1.37-1.43 13.7-14.3 ≥1011 ≥12.7 ≥1353 ≥17 358-390 45-49 ≤120 ≥7.5
    N50H 1.40-1.45 14.0-14.5 ≥1027 ≥12.9 ≥1353 ≥17 374-406 47-51 ≤120 ≥7.5
    N52H 1.42-1.48 14.2-14.8 ≥1059 ≥13.3 ≥1353 ≥17 390-422 49-53 ≤120 ≥7.5
    N33SH 1.14-1.21 11.4-12.1 ≥852 ≥10.7 ≥1592 ≥20 247-279 31-35 ≤150 ≥7.5
    N35SH 1.17-1.24 11.7-12.4 ≥876 ≥11.0 ≥1592 ≥20 263-295 33-37 ≤150 ≥7.5
    N38SH 1.23-1.29 12.3-12.9 ≥915 ≥11.5 ≥1592 ≥20 287-318 36-40 ≤150 ≥7.5
    N40SH 1.26-1.32 12.6-13.2 ≥939 ≥11.8 ≥1592 ≥20 302-334 38-42 ≤150 ≥7.5
    N42SH 1.29-1.35 12.9-13.5 ≥963 ≥12.1 ≥1592 ≥20 318-350 40-44 ≤150 ≥7.5
    N45SH 1.32-1.38 13.2-13.8 ≥987 ≥12.4 ≥1592 ≥20 334-366 42-46 ≤150 ≥7.5
    to be conRnued

    Grade

        Remanence Induction

    Coercivity

    Intrinsic Coercivity

    Maximum Energy product

    WorkingTemperature

    Density

    Br

    HcB

    		 HcJ

    (BH)max

    Tw

    ρ

    Grade

    T

    KGs

    KA/m

    KOe

    KA/m

    KOe

    KJ/m³

    MGOe

    ℃

    		 g/cm3
    N48SH 1.37-1.43 13.7-14.3 ≥1011 ≥12.7 ≥1592 ≥20 358-390 45-49 ≤150 ≥7.5
    N50SH 1.40-1.45 14.0-14.5 ≥1027 ≥12.9 ≥1592 ≥20 374-406 47-51 ≤150 ≥7.5
    N52SH 1.42-1.48 14.2-14.8 ≥1035 ≥13 ≥1512 ≥19 390-422 49-53 ≤150 ≥7.5
    N30UH 1.08-1.13 10.8-11.3 ≥796 ≥10.0 ≥1990 ≥25 223-255 28-31 ≤180 ≥7.5
    N33UH 1.14-1.18 11.4-11.8 ≥852 ≥10.5 ≥1990 ≥25 247-279 31-35 ≤180 ≥7.5
    N35UH 1.17-1.24 11.7-12.4 ≥876 ≥11.0 ≥1990 ≥25 263-295 33-37 ≤180 ≥7.5
    N38UH 1.23-1.29 12.3-12.9 ≥915 ≥11.5 ≥1990 ≥25 287-318 36-40 ≤180 ≥7.5
    N40UH 1.26-1.32 12.6-13.2 ≥939 ≥11.8 ≥1990 ≥25 302-334 38-42 ≤180 ≥7.5
    N42UH 1.28-1.35 12.8-13.5 ≥963 ≥12.1 ≥1990 ≥25 310-350 39-44 ≤180 ≥7.5
    N45UH 1.32-1.38 13.2-13.8 ≥987 ≥12.4 ≥1990 ≥25 334-366 42-46 ≤180 ≥7.5
    N48UH 1.37-1.42 13.7-14.2 ≥1019 ≥12.8 ≥1910 ≥24 358-390 45-49 ≤180 ≥7.5
    N30EH 1.08-1.15 10.8-11.5 ≥812 ≥10.2 ≥2388 ≥30 223-255 28-32 ≤200 ≥7.5
    N33EH 1.14-1.21 11.4-12.1 ≥851 ≥10.7 ≥2388 ≥30 247-279 31-35 ≤200 ≥7.5
    N35EH 1.17-1.24 11.7-12.4 ≥876 ≥11.0 ≥2388 ≥30 263-295 33-37 ≤200 ≥7.5
    N38EH 1.23-1.29 12.3-12.9 ≥915 ≥11.5 ≥2388 ≥30 287-318 36-40 ≤200 ≥7.5
    N40EH 1.26-1.32 12.6-13.2 ≥939 ≥11.8 ≥2388 ≥30 302-334 38-42 ≤200 ≥7.5
    N42EH 1.28-1.35 12.8-13.5 ≥963 ≥12.1 ≥2388 ≥30 310-350 39-44 ≤200 ≥7.5
    N45EH 1.33-1.38 13.3-13.8 ≥995 ≥12.5 ≥2308 ≥29 334-366 42-46 ≤200 ≥7.5
    N28AH 1.04-1.12 10.4-11.2 ≥772 ≥9.7 ≥2786 ≥35 207-239 26-30 ≤230 ≥7.5
    N30AH 1.08-1.15 10.8-11.5 ≥812 ≥10.2 ≥2786 ≥35 223-255 28-32 ≤230 ≥7.5
    N33AH 1.14-1.21 11.4-12.1 ≥852 ≥10.7 ≥2786 ≥35 247-279 31-35 ≤230 ≥7.5
    N35AH 1.17-1.24 11.7-12.4 ≥876 ≥11.0 ≥2786 ≥35 263-295 33-37 ≤230 ≥7.5
    N38AH 1.23-1.27 12.3-12.7 ≥923 ≥11.6 ≥2786 ≥35 287-318 36-40 ≤230 ≥7.5
    N40AH 1.26-1.31 12.6-13.1 ≥939 ≥11.8 ≥2628 ≥33 302-334 38-42 ≤230 ≥7.5
    N42AH 1.29-1.35 12.9-13.5 ≥955 ≥12.0 ≥2628 ≥33 318-350 40-44 ≤230 ≥7.5
    to be conRnued
    Grade Remanence Induction Coercivity Intrinsic Coercivity  ๋Maximum Energy
    product    		 Working
    Temperature    		 Density
    Br HcB HcJ (BH)max Tw ρ
    T KGs KA/m KOe KA/m KOe KJ/m³ MGOe ℃ g/cm3
    Diffusion Process
    G48SH 1.37-1.42 13.7-14.2 ≥1011 ≥13 ≥1592 ≥20 358-390 45-49 ≤150 ≥7.5
    G50SH 1.40-1.45 14.0-14.5 ≥1027 ≥13.2 ≥1592 ≥20 374-406 47-51 ≤150 ≥7.5
    G52SH 1.42-1.48 14.2-14.8 ≥1067 ≥13.4 ≥1592 ≥20 390-422 49-53 ≤150 ≥7.5
    G55SH 1.46-1.51 14.6-15.1 ≥1083 ≥13.6 ≥1592 ≥20 406-438 51-55 ≤150 ≥7.5
    G45UH 1.33-1.38 13.3-13.8 ≥978 ≥12.4 ≥1990 ≥25 334-366 42-46 ≤180 ≥7.5
    G48UH 1.37-1.42 13.7-14.2 ≥1027 ≥12.9 ≥1990 ≥25 358-390 45-49 ≤180 ≥7.5
    G50UH 1.40-1.45 14.0-14.5 ≥1051 ≥13.2 ≥1990 ≥25 374-406 47-51 ≤180 ≥7.5
    G52UH 1.42-1.48 14.2-14.8 ≥1067 ≥13.4 ≥1990 ≥25 390-422 49-53 ≤180 ≥7.5
    G54UH 1.46-1.51 14.6-15.1 ≥1075 ≥13.5 ≥1990 ≥25 406-438 51-55 ≤180 ≥7.5
    G40EH 1.26-1.31 12.6-13.1 ≥955 ≥12.0 ≥2388 ≥30 302-334 38-42 ≤200 ≥7.5
    G44EH 1.29-1.35 12.9-13.5 ≥971 ≥12.2 ≥2388 ≥30 318-350 40-44 ≤200 ≥7.5
    G46EH 1.33-1.38 13.3-13.8 ≥1011 ≥12.7 ≥2388 ≥30 334-366 42-46 ≤200 ≥7.5
    G48EH 1.37-1.42 13.7-14.2 ≥1027 ≥12.9 ≥2388 ≥30 358-390 45-49 ≤200 ≥7.5
    G50EH 1.40-1.45 14.0-14.5 ≥1051 ≥13.2 ≥2308 ≥29 374-406 47-51 ≤200 ≥7.5

    Product description

    Circular Disc Industrial magnet pure permanent magnet, that is, circular industrial magnet, is a pure permanent magnet with strong magnetic attraction and excellent stability. The following is a detailed introduction to this product:

    Features:

    Strong magnetic attraction: Circular industrial magnets are made of high-performance rare earth materials, such as neodymium iron boron (NdFeB), etc., which have extremely high magnetic energy product and coercive force, can produce strong magnetic attraction, and are suitable for various applications that require strong adsorption. industrial applications.

    Excellent stability: This kind of magnet has good temperature stability and corrosion resistance, can maintain stable magnetic properties in harsh working environments, and is not easily affected by external factors.

    Diverse sizes and specifications: Circular industrial magnets can be customized with different diameters, thicknesses and magnetic pole configurations according to customer needs to meet the needs of various application scenarios.

    Easy to process and install: The surface of the magnet is flat and smooth, making it easy to drill, cut, paste and other processing operations, making it convenient for customers to customize and install according to their needs.

    Application areas:

    Industrial machinery: used in various mechanical equipment that require magnetic adsorption, such as automated production lines, material conveying systems, magnetic separation equipment, etc.

    Electronic equipment: used in the manufacturing of electronic equipment such as speakers, sensors, motors, etc. to provide stable magnetic support.

    Medical equipment: used in medical equipment such as magnetic resonance imaging (MRI) to provide powerful magnetic fields for imaging diagnosis.

    Environmental protection field: used for magnetic separation to separate magnetic substances in waste to achieve resource recovery and environmental protection.
