Rectangular bar of pure silver permanent magnets

Pure permanent magnet

A sterling silver rectangular permanent magnet refers to a rectangular-shaped permanent magnet with a silver design or decoration. Such magnets are useful in applications that require strong and long-lasting magnetism, such as motors, speakers, and medical equipment.

Contact Us
  • Specifications
  • Do You Have Any Question?
  • Grade Remanenz Induktion Koerzitivfeldstärke Intrinsische Koerzitivfeldstärke  Maximal Energie Produkt Arbeitstemperatur Dichte
    Br HcB HcJ (BH)max Tw ρ
    T KGs KA/m KOe KA/m KOe KJ/m³ MGOe ℃ g/cm3
    Allgemeiner Prozess
    N38 1.23-1.30 12.3-13.0 ≥876 ≥11 ≥955 ≥12 287-318 36-40 ≤80 ≥7.5
    N40 1.26-1.32 12.6-13.2 ≥876 ≥11 ≥955 ≥12 302-334 38-42 ≤80 ≥7.5
    N42 1.29-1.35 12.9-13.5 ≥876 ≥11 ≥955 ≥12 318-350 40-44 ≤80 ≥7.5
    N45 1.32-1.38 13.2-13.8 ≥876 ≥11 ≥955 ≥12 334-366 42-46 ≤80 ≥7.5
    N48 1.37-1.43 13.7-14.3 ≥876 ≥11 ≥955 ≥12 358-390 45-49 ≤80 ≥7.5
    N50 1.40-1.45 14.0-14.5 ≥876 ≥11 ≥955 ≥12 374-406 47-51 ≤80 ≥7.5
    N52 1.42-1.48 14.2-14.8 ≥836 ≥10.5 ≥876 ≥11 390-422 49-53 ≤80 ≥7.5
    N55 1.46-1.51 14.6-15.1 ≥860 ≥10.8 ≥955 ≥12 406-438 51-55 ≤80 ≥7.5
    N38M 1.23-1.30 12.3-13.0 ≥915 ≥11.5 ≥1114 ≥14 287-318 36-40 ≤100 ≥7.5
    N40M 1.26-1.32 12.6-13.2 ≥939 ≥11.8 ≥1114 ≥14 302-334 38-42 ≤100 ≥7.5
    N42M 1.29-1.35 12.9-13.5 ≥963 ≥12.1 ≥1114 ≥14 318-350 40-44 ≤100 ≥7.5
    N45M 1.32-1.38 13.2-13.8 ≥987 ≥12.4 ≥1114 ≥14 334-366 42-46 ≤100 ≥7.5
    N48M 1.37-1.43 13.7-14.3 ≥1019 ≥12.8 ≥1114 ≥14 358-390 45-49 ≤100 ≥7.5
    N50M 1.40-1.45 14.0-14.5 ≥1043 ≥13.1 ≥1114 ≥14 374-406 47-51 ≤100 ≥7.5
    N52M 1.42-1.48 14.2-14.8 ≥1059 ≥13.3 ≥1114 ≥14 390-422 49-53 ≤100 ≥7.5
    N54M 1.46-1.51 14.6-15.1 ≥995 ≥12.5 ≥1035 ≥13 406-438 51-55 ≤100 ≥7.5
    N35H 1.17-1.24 11.7-12.4 ≥876 ≥11.0 ≥1353 ≥17 263-295 33-37 ≤120 ≥7.5
    N38H 1.23-1.30 12.3-13.0 ≥915 ≥11.5 ≥1353 ≥17 286-318 36-40 ≤120 ≥7.5
    N40H 1.26-1.32 12.6-13.2 ≥939 ≥11.8 ≥1353 ≥17 302-334 38-42 ≤120 ≥7.5
    N42H 1.29-1.35 12.9-13.5 ≥963 ≥12.1 ≥1353 ≥17 318-350 40-44 ≤120 ≥7.5
    N45H 1.32-1.38 13.2-13.8 ≥987 ≥12.4 ≥1353 ≥17 334-366 42-46 ≤120 ≥7.5
    N48H 1.37-1.43 13.7-14.3 ≥1011 ≥12.7 ≥1353 ≥17 358-390 45-49 ≤120 ≥7.5
    N50H 1.40-1.45 14.0-14.5 ≥1027 ≥12.9 ≥1353 ≥17 374-406 47-51 ≤120 ≥7.5
    N52H 1.42-1.48 14.2-14.8 ≥1059 ≥13.3 ≥1353 ≥17 390-422 49-53 ≤120 ≥7.5
    N33SH 1.14-1.21 11.4-12.1 ≥852 ≥10.7 ≥1592 ≥20 247-279 31-35 ≤150 ≥7.5
    N35SH 1.17-1.24 11.7-12.4 ≥876 ≥11.0 ≥1592 ≥20 263-295 33-37 ≤150 ≥7.5
    N38SH 1.23-1.29 12.3-12.9 ≥915 ≥11.5 ≥1592 ≥20 287-318 36-40 ≤150 ≥7.5
    N40SH 1.26-1.32 12.6-13.2 ≥939 ≥11.8 ≥1592 ≥20 302-334 38-42 ≤150 ≥7.5
    N42SH 1.29-1.35 12.9-13.5 ≥963 ≥12.1 ≥1592 ≥20 318-350 40-44 ≤150 ≥7.5
    N45SH 1.32-1.38 13.2-13.8 ≥987 ≥12.4 ≥1592 ≥20 334-366 42-46 ≤150 ≥7.5
    Fortsetzung folgt

    Grade

    Remanenz Induktion

    Koerzitivfeldstärke

    Intrinsische Koerzitivfeldstärke

    Maximal Energie Produkt

    Arbeitstemperatur

    Dichte

    Br

    HcB

    		 HcJ

    (BH)max

    Tw

    ρ

    Grade

    T

    KGs

    KA/m

    KOe

    KA/m

    KOe

    KJ/m³

    MGOe

    ℃

    		 g/cm3
    N48SH 1.37-1.43 13.7-14.3 ≥1011 ≥12.7 ≥1592 ≥20 358-390 45-49 ≤150 ≥7.5
    N50SH 1.40-1.45 14.0-14.5 ≥1027 ≥12.9 ≥1592 ≥20 374-406 47-51 ≤150 ≥7.5
    N52SH 1.42-1.48 14.2-14.8 ≥1035 ≥13 ≥1512 ≥19 390-422 49-53 ≤150 ≥7.5
    N30UH 1.08-1.13 10.8-11.3 ≥796 ≥10.0 ≥1990 ≥25 223-255 28-31 ≤180 ≥7.5
    N33UH 1.14-1.18 11.4-11.8 ≥852 ≥10.5 ≥1990 ≥25 247-279 31-35 ≤180 ≥7.5
    N35UH 1.17-1.24 11.7-12.4 ≥876 ≥11.0 ≥1990 ≥25 263-295 33-37 ≤180 ≥7.5
    N38UH 1.23-1.29 12.3-12.9 ≥915 ≥11.5 ≥1990 ≥25 287-318 36-40 ≤180 ≥7.5
    N40UH 1.26-1.32 12.6-13.2 ≥939 ≥11.8 ≥1990 ≥25 302-334 38-42 ≤180 ≥7.5
    N42UH 1.28-1.35 12.8-13.5 ≥963 ≥12.1 ≥1990 ≥25 310-350 39-44 ≤180 ≥7.5
    N45UH 1.32-1.38 13.2-13.8 ≥987 ≥12.4 ≥1990 ≥25 334-366 42-46 ≤180 ≥7.5
    N48UH 1.37-1.42 13.7-14.2 ≥1019 ≥12.8 ≥1910 ≥24 358-390 45-49 ≤180 ≥7.5
    N30EH 1.08-1.15 10.8-11.5 ≥812 ≥10.2 ≥2388 ≥30 223-255 28-32 ≤200 ≥7.5
    N33EH 1.14-1.21 11.4-12.1 ≥851 ≥10.7 ≥2388 ≥30 247-279 31-35 ≤200 ≥7.5
    N35EH 1.17-1.24 11.7-12.4 ≥876 ≥11.0 ≥2388 ≥30 263-295 33-37 ≤200 ≥7.5
    N38EH 1.23-1.29 12.3-12.9 ≥915 ≥11.5 ≥2388 ≥30 287-318 36-40 ≤200 ≥7.5
    N40EH 1.26-1.32 12.6-13.2 ≥939 ≥11.8 ≥2388 ≥30 302-334 38-42 ≤200 ≥7.5
    N42EH 1.28-1.35 12.8-13.5 ≥963 ≥12.1 ≥2388 ≥30 310-350 39-44 ≤200 ≥7.5
    N45EH 1.33-1.38 13.3-13.8 ≥995 ≥12.5 ≥2308 ≥29 334-366 42-46 ≤200 ≥7.5
    N28AH 1.04-1.12 10.4-11.2 ≥772 ≥9.7 ≥2786 ≥35 207-239 26-30 ≤230 ≥7.5
    N30AH 1.08-1.15 10.8-11.5 ≥812 ≥10.2 ≥2786 ≥35 223-255 28-32 ≤230 ≥7.5
    N33AH 1.14-1.21 11.4-12.1 ≥852 ≥10.7 ≥2786 ≥35 247-279 31-35 ≤230 ≥7.5
    N35AH 1.17-1.24 11.7-12.4 ≥876 ≥11.0 ≥2786 ≥35 263-295 33-37 ≤230 ≥7.5
    N38AH 1.23-1.27 12.3-12.7 ≥923 ≥11.6 ≥2786 ≥35 287-318 36-40 ≤230 ≥7.5
    N40AH 1.26-1.31 12.6-13.1 ≥939 ≥11.8 ≥2628 ≥33 302-334 38-42 ≤230 ≥7.5
    N42AH 1.29-1.35 12.9-13.5 ≥955 ≥12.0 ≥2628 ≥33 318-350 40-44 ≤230 ≥7.5
    Fortsetzung folgt
    Grade Remanenz Induktion Koerzitivfeldstärke Intrinsische Koerzitivfeldstärke Maximal Energie Produkt Arbeitstemperatur Dichte
    Br HcB HcJ (BH)max Tw ρ
    T KGs KA/m KOe KA/m KOe KJ/m³ MGOe ℃ g/cm3
    Diffusionsprozess
    G48SH 1.37-1.42 13.7-14.2 ≥1011 ≥13 ≥1592 ≥20 358-390 45-49 ≤150 ≥7.5
    G50SH 1.40-1.45 14.0-14.5 ≥1027 ≥13.2 ≥1592 ≥20 374-406 47-51 ≤150 ≥7.5
    G52SH 1.42-1.48 14.2-14.8 ≥1067 ≥13.4 ≥1592 ≥20 390-422 49-53 ≤150 ≥7.5
    G55SH 1.46-1.51 14.6-15.1 ≥1083 ≥13.6 ≥1592 ≥20 406-438 51-55 ≤150 ≥7.5
    G45UH 1.33-1.38 13.3-13.8 ≥978 ≥12.4 ≥1990 ≥25 334-366 42-46 ≤180 ≥7.5
    G48UH 1.37-1.42 13.7-14.2 ≥1027 ≥12.9 ≥1990 ≥25 358-390 45-49 ≤180 ≥7.5
    G50UH 1.40-1.45 14.0-14.5 ≥1051 ≥13.2 ≥1990 ≥25 374-406 47-51 ≤180 ≥7.5
    G52UH 1.42-1.48 14.2-14.8 ≥1067 ≥13.4 ≥1990 ≥25 390-422 49-53 ≤180 ≥7.5
    G54UH 1.46-1.51 14.6-15.1 ≥1075 ≥13.5 ≥1990 ≥25 406-438 51-55 ≤180 ≥7.5
    G40EH 1.26-1.31 12.6-13.1 ≥955 ≥12.0 ≥2388 ≥30 302-334 38-42 ≤200 ≥7.5
    G44EH 1.29-1.35 12.9-13.5 ≥971 ≥12.2 ≥2388 ≥30 318-350 40-44 ≤200 ≥7.5
    G46EH 1.33-1.38 13.3-13.8 ≥1011 ≥12.7 ≥2388 ≥30 334-366 42-46 ≤200 ≥7.5
    G48EH 1.37-1.42 13.7-14.2 ≥1027 ≥12.9 ≥2388 ≥30 358-390 45-49 ≤200 ≥7.5
    G50EH 1.40-1.45 14.0-14.5 ≥1051 ≥13.2 ≥2308 ≥29 374-406 47-51 ≤200 ≥7.5

    Product description

    Rectangular Bar of Silver-based Alloy Permanent Magnet

    Features:

    Material composition: Using advanced silver-based alloy materials, combined with permanent magnet manufacturing technology, to ensure that the product has excellent magnetic properties and stability.
    Shape and size: The product is rectangular in design, and the length, width and thickness can be customized according to customer needs.
    Magnetic properties: It has the characteristics of high remanence, high coercivity and low hysteresis loop, ensuring its magnetic stability in various environments.
    Stability: good corrosion resistance and oxidation resistance, can be used in a variety of environments for a long time without affecting its magnetic properties.
    Wide range of applications: suitable for various equipment or systems that require strong magnetic field environments.

    Product application scope:
    Motors and generators: Used to manufacture high-performance motors and generators to improve energy conversion efficiency.
    Sensors and instruments: As the core components of magnetic field sensors or instruments, they are used to measure, detect and control magnetic field intensity.
    Medical equipment: such as magnetic resonance imaging (MRI) equipment, magnetic therapy equipment, etc., providing a stable and uniform magnetic field environment.
    Aerospace: used to manufacture navigation equipment, attitude control systems, etc. to ensure precise navigation and stable control of aircraft.
    Scientific research and teaching: As magnetic experimental equipment for laboratory teaching and scientific research, it helps students and scientific researchers have an in-depth understanding of the principles and applications of magnetism.

    Precautions:
    Do not expose the product to extreme temperatures or humidity as this may affect its magnetic properties and stability.
    Do not bring the product into close contact with sources of strong magnetic fields to avoid magnetic field interference or damage to the product.
    When handling the product, wear protective gloves and glasses to avoid eye damage from scratches or splashes.
